1.Monolithic inorganic material construction.
2.Closed magnetic circuit avoids crosstalk.
3.S.M.T. type.
4.Suitable for flow and reflow soldering.
5.Shapes and dimensions follow E.I.A. spec.
6.Available in various sizes.
7.Excellent solder ability and heat resistance.
8.High reliability.
9.This component is compliant with RoHS legislation and also support lead-free soldering.
Dimension
| Size | A(mm) | B(mm) | C(mm) | D(mm) |
| 1608F | 1.6±0.15 | 0.8±0.15 | 0.8±0.15 | 0.3±0.2 |
| 1608TF | 1.8±0.15 | 0.8±0.15 | 0.8±0.15 | 0.3±0.2 |
| 2012F | 2.0±0.2 | 1.25±0.2 | 0.85±0.2 | 0.5±0.3 |
| 2012F | 2.0±0.2 | 1.25±0.2 | 1.25±0.2 | 0.5±0.3 |
Part Numbering
| Part Number | Thickness C size (mm) | Inductance(uH) | Q min. | Test Frequency (MHz) | Rated Current(mA) max. | DC Resistance(Ω) max. | SRF(MHz) min. |
|---|---|---|---|---|---|---|---|
| FCI1608F-47N□ | 0.8±0.15 | 0.047 | 10 | 50 | 50 | 0.3 | 260 |
| FCI1608F-68N□ | 0.8±0.15 | 0.068 | 10 | 50 | 50 | 0.3 | 250 |
| FCI1608F-82N□ | 0.8±0.15 | 0.082 | 10 | 50 | 50 | 0.3 | 245 |
| FCI1608F-R10□ | 0.8±0.15 | 0.1 | 15 | 25 | 50 | 0.5 | 240 |
| FCI1608F-R12□ | 0.8±0.15 | 0.12 | 15 | 25 | 50 | 0.5 | 205 |
| FCI1608F-R15□ | 0.8±0.15 | 0.15 | 15 | 25 | 50 | 0.6 | 180 |
| FCI1608F-R18□ | 0.8±0.15 | 0.18 | 15 | 25 | 50 | 0.6 | 165 |
| FCI1608F-R22□ | 0.8±0.15 | 0.22 | 15 | 25 | 50 | 0.8 | 150 |
| FCI1608F-R27□ | 0.8±0.15 | 0.27 | 15 | 25 | 50 | 0.8 | 136 |
| FCI1608F-R33□ | 0.8±0.15 | 0.33 | 15 | 25 | 35 | 0.85 | 125 |
