Low loss realized with low DCR.
High performance realized by metal dust core.
Ultra low buzz noise, due to composite construction.
100% Lead(Pb)-Free and RoHS compliant.
High reliability -Reliability test complied to AEC-Q200.
leadframe
non-leadframe
| Size | A(mm) | B(mm) | C(mm) | D(mm) | E(mm) | T(mm) | Inductance |
| 1004 | 11.0±0.3 | 10.0±0.3 | 3.8±0.2 | 2.0±0.3 | 2.5±0.3 | 0~0.2 | 0.56~1.50uH among |
| 1004 | 11.0±0.3 | 10.0±0.3 | 3.8±0.2 | 2.0±0.3 | 3.0±0.3 | 0~0.2 | 0.47uH and below;2.20uH and above |
| 1205 | 13.5±0.5 | 12.6±0.2 | 4.7±0.3 | 2.3±0.3 | 4.0±0.3 | 1.0uH and below | |
| 1205 | 13.5±0.5 | 12.6±0.2 | 4.7±0.3 | 2.3±0.3 | 4.7±0.3 | 1.5uH and above | |
| 1206 | 13.5±0.5 | 12.6±0.2 | 5.7±0.3 | 2.3±0.3 | 4.7±0.3 | ||
| 1265 | 13.5±0.5 | 12.6±0.2 | 6.2±0.3 | 2.3±0.3 | 4.0±0.3 | 0.68~1.50uH among | |
| 1265 | 13.5±0.5 | 12.6±0.2 | 6.2±0.3 | 2.3±0.3 | 4.7±0.3 | 0.22uH and below;2.20uH and above | |
| 1707 | 17.8±0.5 | 16.9±0.3 | 6.7±0.3 | 2.3±0.3 | 11.9±0.3 | ||
| 2313 | 23.5±0.5 | 22.0±0.3 | 12.6±0.4 | 5.0±0.4 | 19.0±0.3 |
| FMPA | 1004 | SV | - | 1R0 | MN | - D |
| A | B | C | D | E | F | |
| FMPA | 1205 | SPV | - | 120 | MN | - D |
| A | B | C | D | E | F |
 | A: | Series |
| B: | Dimension (B x C ) |
| C: | Type ,Standard. |
| D: | Inductance (R10=0.1uh，1R0=1.0uh，100=10uh，101=100uh，102=1000uh. ) |
| E: | Inductance Tolerance ,K=±10%，L=±15%，M=±20%，N=±25%，Y=±30% |
| F: | Code (" Marking: Black.1R0 and 1537(15 YY,37 WW) (follow production date)." ) |
| Part Number | Inductance | I rms(A) Typ. | I rms(A) Max. | Isat(A) Typ. | Isat(A) Max. | DCR(mΩ) Typ. | DCR(mΩ) Max. |
|---|---|---|---|---|---|---|---|
| FMPA0603SV-R15YN-D | 0.15±30% | 30 | / | 40 | / | 1.7 | 2.1 |
| FMPA0603SV-R22MN-D | 0.22 | 23 | / | 34 | / | 2 | 2.5 |
| FMPA0603SV-R33MN-D | 0.33 | 21 | / | 25 | / | 2.8 | 3.4 |
| FMPA0603SV-R36MN-D | 0.36 | 20 | / | 24 | / | 3.3 | 3.9 |
| FMPA0603SV-R47MN-D | 0.47 | 18 | / | 20 | / | 3.4 | 4 |
| FMPA0603SV-R56MN-D | 0.56 | 16.5 | / | 18 | / | 3.9 | 4.5 |
| FMPA0603SV-R68MN-D | 0.68 | 16 | / | 17 | / | 4.7 | 5.3 |
| FMPA0603SV-R82MN-D | 0.82 | 14 | / | 16 | / | 5.4 | 6 |
| FMPA0603SV-1R0MN-D | 1 | 12 | / | 15 | / | 6.7 | 7.4 |
| FMPA0603SV-1R2MN-D | 1.2 | 10 | / | 14 | / | 7.7 | 9.5 |
