Part Number	Inductance L0 (uH)±20%	I rms ( A ) Typ	I sat ( A ) Typ	DCR(mΩ) Typ.@25℃	DCR(mΩ) Max.@25℃
Part Number	Inductance L0 (uH)±20%	I rms ( A ) Typ	I sat ( A ) Typ	DCR(mΩ) Typ.@25℃	DCR(mΩ) Max.@25℃
LTC0312HV-R15YG	0.15±30%	10	14	9.6	11
LTC0312HV-R22MG	0.22	6.5	10	14	17
LTC0312HV-R33MG	0.33	6.2	9.2	16	20
LTC0312HV-R36MG	0.36	6	8.5	18.5	23
LTC0312HV-R47MG	0.47	5	7.2	25	30
LTC0312HV-R56MG	0.56	4.5	6.6	31	36
LTC0312HV-R68MG	0.68	4	6.1	34	40
LTC0312HV-R82MG	0.82	3.5	5.8	41	48
LTC0312HV-1R0MG	1	3.3	5.5	50	60
