| 1. Shielded construction. |
| 2. Capable of corresponding high frequency . |
| 3. Low loss realized with low DCR. |
| 4. High performance (Isat) realized by metal dust core. |
| 5. Ultra low buzz noise, due to composite construction. |
| 6. 100% Lead(Pb)-Free and RoHS compliant. |
| 7. High reliability -Reliability test complied to AEC-Q200. |
| 8. Operating temperature -55~+155℃(Including self - temperature rise) |
| LTA | 1265 | SPV | - | 100 | MN | - | D |
| A | B | C | D | E | F |
A: Series
B: Dimension BxC.
C: Type Standard. P:PAD broaden. V=Vehicle.
D: Inductance R10=0.1uh，1R0=1.0uh，100=10uh，101=100uh，102=1000uh.
E: Inductance Tolerance K=±10%，L=±15%，M=±20%，N=±25%，Y=±30%
F: Code Marking: Black.100 and 2114(21 YY,14 WW,follow production date).
| Part Number | Inductance L0 (uH)±20% | I rms ( A ) Typ | I rms ( A ) Max | I sat ( A ) Typ | I sat ( A ) Max | DCR(mΩ) Typ | DCR(mΩ) Max | E(mm) ±0.3 |
|---|---|---|---|---|---|---|---|---|
| LTA0402SPV-R10MN | 0.1 | 16 | 14 | 26 | 22 | 2.9 | 3.2 | / |
| LTA0402SPV-R22MN | 0.22 | 14 | 12.5 | 15 | 13 | 4.8 | 5.5 | / |
| LTA0402SPV-R33MN | 0.33 | 12 | 11 | 10.5 | 9.5 | 7.5 | 8.3 | / |
| LTA0402SPV-R47MN | 0.47 | 10 | 9 | 9 | 8 | 9.5 | 11 | / |
| LTA0402SPV-R68MN | 0.68 | 9 | 8 | 7.6 | 6.6 | 11.6 | 13.5 | / |
| LTA0402SPV-R82MN | 0.82 | 8 | 7 | 6 | 5.5 | 16.3 | 18.8 | / |
| LTA0402SPV-1R0MN | 1 | 7.5 | 6.5 | 5.5 | 5 | 19 | 22 | / |
| LTA0402SPV-1R5MN | 1.5 | 6.7 | 5.8 | 5.2 | 4.8 | 27 | 31 | / |
| LTA0402SPV-2R2MN | 2.2 | 5.5 | 5 | 4.5 | 4 | 41 | 48 | / |
| LTA0402SPV-3R3MN | 3.3 | 4.5 | 3.5 | 3.1 | 2.7 | 65 | 75 | / |
